EAP725-Outdoor
Omada BE3600 Indoor/Outdoor Wi-Fi 7 Access Point with Directional/Omnidirectional Antennas
-
Switchable Directional and Omnidirectional Antennas: Supports focused point coverage or wide-area outdoor coverage by switching antenna modes on software.
-
Plug & Play Automatic Antenna Detection: Automatically detects when external antennas are installed and adjusts the coverage pattern accordingly.
-
4-Stream Outdoor Wi-Fi 7: Delivers high-speed outdoor connectivity up to 3.6 Gbps.
-
True Dual-Band Coverage: 300 m omnidirectional and 510 m directional recommended coverage.
-
1× 2.5G PoE Port: Flexible PoE deployment reduces costs by delivering power and data over a single Ethernet cable.
-
Outdoor-Ready Durability: Features an IP66-rated weatherproof enclosure and 6kV lightning protection.
-
Quick and Easy Setup: Features wall/pole mounting withOmada SDN for one-click setup.
-
Advanced Features: Centralised management, mesh, and seamless roaming.
Versatile Antennas Deployment
Adapt to any environment effortlessly by selecting the antenna type that suits your needs. Whether you require long-distance connectivity or need to cover multiple endpoints, easily switch between external omni, internal directional, or custom antenna configurations with just a few clicks in the software.
SPECIFICATIONS
| HARDWARE FEATURES |
| Interface |
1 x 10M/100M/1000M/2.5Gbps Ethernet Port (RJ45) |
| Button |
Reset |
| Power Supply |
802.3at PoE |
| Max. Power Consumption |
18.4W (for PoE+) |
| Dimensions ( W x D x H ) |
8.19 x 6.3 x 2.17 in (208 × 160 × 55 mm) |
| Antenna |
• 2.4 GHz:
2 × 4.5 dBi, external omnidirectional antennas
2 × 8.3 dBi, internal directional antennas (antenna beamwidth 90°)
• 5 GHz:
2 × 5.3 dBi, external omnidirectional antennas
2 × 13.2 dBi, internal directional antennas (antenna beamwidth 45°)
Note: The gains above are the single-antenna peak gains. |
| Bluetooth |
BLE 5.2 |
| Weatherproof Enclosure |
IP66 |
| Mounting |
Pole/Wall Mounting (Kits included) |
| WIRELESS FEATURES |
| Wireless Standards |
IEEE 802.11a/g/b/n/ac/ax/be |
| Frequency |
2.4 GHz, 5 GHz |
| Signal Rate |
688 Mbps (2.4 GHz) + 2882 Mbps (5 GHz) |
| Wireless Functions |
• 4k-QAM
• OFDMA
• Multiple SSIDs: 16 (8 for each band)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS (WMM)
• MLO
• Omada Mesh§
• Seamless Roaming(802.11k/v/r)§
• Band Steering
• Load Balance
• Airtime Fairness
• Beamforming
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics based on SSID/AP/Client
• Static IP/Dynamic lP |
| Wireless Security |
• Captive Portal Authentication§
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Rogue AP Detection
• 802.1X Support
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, OWE |
| Transmission Power |
• CE: (EIRP)
2.4 GHz: 20 dBm
5 GHz: 23 dBm in U-NII-1, 23 dBm in U-NII-2A, 30 dBm in U-NII-2C
• FCC: (Conducted Power)
2.4 GHz: 25 dBm
5 GHz: 26 dBm in U-NII-1, 24 dBm in U-NII-2A, 24 dBm in U-NII-2C, 26 dBm in U-NII-3 |
| Management Features |
| Omada App |
Yes |
| Centralized Management |
• Omada Cloud-Based Controller
• Omada Hardware Controller
• Omada Software Controller
|
| Cloud Access |
Yes. Require the use of an Omada controller. |
| Email Alerts |
Yes |
| Management MAC Access Control |
Yes |
| SNMP |
v1, v2c, v3 |
| System Logging Local/Remote Syslog |
Yes |
| SSH |
Yes |
| Web-based Management |
Yes |
| L3 Management |
Yes |
| Multi-site Management |
Yes |
| Management VLAN |
Yes |
| Zero-Touch Provisioning |
Yes. Requiring the use of Omada Cloud-Based Controller |
| OTHERS |
| Certification |
CE, FCC, RoHS, IC, NCC, VCCI, JRF, BSMI |
| Package Content |
• Access Point EAP725-Outdoor
• Waterproof Kit
• Mounting Kit
• Installation Guide |
| System Requirements |
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Environment |
• Operating Temperature: -30 to 70 ℃ (-22 to 158 ℉)
• Storage Temperature: -40 to 70 ℃ (-40 to 158 ℉)
• Operating Humidity: 10 to 90% RH non-condensing
• Storage Humidity: 5 to 90% RH non-condensing |
| Weight |
Main Unit: 1.33 kg |
