N300 4G LTE Telephony WiFi Router
- Cutting-edge 4G network – share internet access with up to 32 Wi-Fi devices and enjoy download speeds of up to 150 Mbps*
- Plug a SIM card and play – no configurations needed, compatibility for SIM cards in 100+ countries is assured by years of field tests
- WiFi speeds up to 300 Mbps – enjoy uninterrupted HD movies, rapid file downloads, seamless video chats, and more at the same time*
- Professional voice functions – supports VoLTE/CSFB/VoIP functions and provides 50 MB of internal storage for 100 minutes of voicemail
- Two detachable advanced LTE antennas – enjoy stable and efficient connections to every device thanks to the two external antennas
- Wi-Fi router mode – plug an Ethernet cable into the LAN/WAN port for flexible access if you can't get a 4G connection
| HARDWARE FEATURES |
| Interface |
1× 10/100 Mbps LAN/WAN Port, 2× 10/100 Mbps LAN Ports, 1× Phone Port, 1 Nano SIM Card Slot |
| Button |
WPS/RESET Button, Wi-Fi ON/OFF Button |
| External Power Supply |
12V/1A |
| Dimensions ( W x D x H ) |
7.95 × 5.55 × 1.32 in (202 × 141 × 33.6 mm) |
| Antenna |
2× Detachable External 4G LTE Antennas |
| WIRELESS FEATURES |
| Wireless Standards |
IEEE 802.11b, 802.11g, 802.11n |
| Frequency |
2.4 GHz |
| Signal Rate |
300Mbps at 2.4GHz |
| Reception Sensitivity |
11g 54M: -74 dBm
11n HT20: -71 dBm
11n HT40: -67 dBm |
| Wireless Functions |
Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless
Statistics |
| WAN Failover |
Yes |
| Wireless Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions |
| Network Type |
4G: FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz)
3G: DC-HSPA+/HSPA/UMTS: B1/B5/B8(2100/850/900 Mhz) |
| SOFTWARE FEATURES |
| Quality of Service |
WMM, QoS |
| Operating Modes |
3G/4G Router, Wireless Router |
| WAN Type |
Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access) |
| Management |
Access Control, Local Management, Remote Management |
| DHCP |
Server, Client, DHCP Client List, Address Reservation |
| Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS |
TP-Link DDNS, DynDns, NO-IP |
| VPN Pass-Through |
PPTP, L2TP, IPSec |
| Access Control |
Parental Controls, Local Management Control, Host List, Access Control |
| Firewall Security |
DoS, SPI Firewall, IP and MAC Address Binding |
| Protocols |
Supports IPv4 and IPv6 |
| Guest Network |
2.4 GHz Guest Network |
| VPN Server |
PPTP VPN, OpenVPN |
| TELEPHONY |
| VoIP Standards |
SIP(RFC3261)/RTP(RFC1889/3550), G.711A/u, G.729AB, G.726 |
| Integrated Answering Machine |
Stores 100 minutes long voice messages internally on the modem router |
| Advanced Telephone Functions |
Call Blocking, Anonymous Call Blocks, Speed Dial, Emergency Number
|
| OTHERS |
| Certification |
CE, RoHS |
| Package Contents |
300 Mbps Wireless N 4G LTE Telephony Router, TL-MR6500v
RJ45 Ethernet Cable
Power Adapter
Quick Installation Guide |
| System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10
MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 browsers or higher, or other Java-enabled browsers Nano SIM Card
|
| Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and client location.
